技术指标
|
||
高功率高损伤阈值
|
>15j/cm^2@1064nm 20ns,20hz
or >2mw/cm^2 cw @lc
|
|
尺寸公差
|
±0.1 mm, or better upon request
|
|
表面图
|
<1/4 wave@633nm
|
|
表面质量
|
40/20 scratch/dig
|
|
光束偏差
|
<1 arc min
|
|
消光比
|
>30db
|
|
主传动tp
|
窄带
|
tp>97% @ λc
|
宽带
|
t_avg>95%
|
|
主反射rs
|
rs>99.5%
|
|
波长范围
|
窄带(lc,nm)
|
355, 532, 633, 780, 850, 920, 980, 1064, etc.
|
宽带(nm)
|
450-650, 650-900, 900-1200, 1200-1600, etc.
|
|
增透膜
|
@all input & output surface
|
size(mm) |
part no. |
3.2x3.2x3.2 | pbs1401 |
5x5x5 | pbs1402 |
10x10x10 | pbs1403 |
12.7x12.7x12.7 | pbs1404 |
15x15x15 | pbs1405 |
size(mm) |
part no. |
3.2x3.2x3.2 |
pbs5401 |
5x5x5 |
pbs5402 |
10x10x10 |
pbs5403 |
12.7x12.7x12.7 |
pbs5404 |
15x15x15 |
pbs5405 |
pbs @ 633± 20nm,tp>96%,tp:ts>3000:1
订购信息
零件编号-波长
例如pbs1401-1064nm,用于高功率pbs 5x5x5mm,1064nm窄带涂层
