沃拉斯顿偏光片
 |
 |
 |
 |
|
 |
| 材料： | a -bbo, calcite, yvo4, quartz | |
| 波长范围： | a -bbo:200-3500 nm,calcite:350-2300 nm,yvo4:400-5000nm,quartz:200-2300nm | |
| 消光比： | calcite, quartz:<5x10 -5 ; a -bbo, yvo4:<5x10 -6 | |
| 并行性： | <1 arc min |  |
| 表面质量： | 20-10 | |
| 光束偏差： | < 3 arc minutes | |
| 波前失真： | l/4@633nm | |
| 损坏阈值： | >500 mw/cm 2 | |
| 涂层： | single mgf2 | |
| 安装： | black anodized aluminium | |
| part no. | extinction ratio | separation angle(°) | c.a. φa (mm) | o.d. φ d (mm) | l±0.1(mm) |
| wsp6006 | <5x10 -6 | 15°- 27 °16°@800nm | 5 | 15 | 9 |
| wsp6008 | 7 | 25.4 | 11 | ||
| wsp6010 | 9 | 25.4 | 13 | ||
| wsp6015 | 13.5 | 30 | 18 | ||
| wsp6020 | 18 | 38 | 24 |
| part no. | extinction ratio | separation angle(°) | c.a. φ a (mm) | o.d. φ d (mm) | l±0.1 |
| (mm) | |||||
| wsp7006 | <5x10 -5 | 16.7°-22.5°19°@980nm | 5 | 15 | 9 |
| wsp7008 | 7 | 25.4 | 11 | ||
| wsp7010 | 9 | 25.4 | 13 | ||
| wsp7015 | 13.5 | 30 | 18 | ||
| wsp7020 | 18 | 38 | 24 |
| part no. | extinction ratio | separation angle(°) | c.a. φ a (mm) | o.d. φ d (mm) | l±0.1 | unit price |
| (mm) | ||||||
| wsp9006 | <5x10 -5 | 2°-3 °2°@1064nm | 5 | 15 | 14 | $149.00 |
| wsp9008 | 7 | 25.4 | 18 | $199.00 | ||
| wsp9010 | 9 | 25.4 | 22 | $249.00 | ||
| wsp9015 | 13.5 | 30 | 32 | $359.00 | ||
| wsp9020 | 18 | 38 | 44 | $539.00 |
| part no. | extinction ratio | separation angle(°) | c.a. φ a (mm) | o.d. φ d (mm) | l±0.1 |
| (mm) | |||||
| wsp8006 | <5x10 -5 | 19.6°-23.3°20°@1550nm | 5 | 15 | 8 |
| wsp8008 | 7 | 25.4 | 10 | ||
| wsp8010 | 9 | 25.4 | 12 | ||
| wsp8015 | 13.5 | 30 | 16 | ||
| wsp8020 | 18 | 38 | 21 |
| part no. | extinction ratio | separation angle(°) | c.a. φ a (mm) | o.d. φ d (mm) | l±0.1 |
| (mm) | |||||
| wsp9006 | <5x10 -5 | 2°-3 °2°@1064nm | 5 | 15 | 14 |
| wsp9008 | 7 | 25.4 | 18 | ||
| wsp9010 | 9 | 25.4 | 22 | ||
| wsp9015 | 13.5 | 30 | 32 | ||
| wsp9020 | 18 | 38 | 44 |
